SST-Porous Schabider Pre-Filtration Oil Mist Filter Vent: High Air Flow for Industrial Systems
The SST-Porous Schabider Pre-Filtration Oil Mist Filter Vent, with models M12.1.5 and M16.1.5, delivers >200–300 l/min air flow and durable stainless steel housing. Ideal for hydraulic systems, gearboxes, and industrial equipment, it ensures contaminant-free ventilation with a quad-ring seal.
The SST-Porous Schabider Pre-Filtration Oil Mist Filter Vent, with models M12.1.5 and M16.1.5, delivers >200–300 l/min air flow and durable stainless steel housing. Ideal for hydraulic systems, gearboxes, and industrial equipment, it ensures contaminant-free ventilation with a quad-ring seal.
In industrial environments like hydraulic systems, gearboxes, and mechanical equipment, effective ventilation is critical to prevent contamination and ensure system longevity. The SST-Porous Schabider Pre-Filtration Oil Mist Filter Vent, available in M12.1.5 and M16.1.5 models, addresses these challenges with advanced filtration technology. Featuring high air flow (>200–300 l/min), stainless steel housing, and a PTFE membrane, it delivers reliable performance in demanding conditions. Developed by SST-Porous, a leader in industrial filtration solutions, this article explores the vent’s features, applications, and proven reliability, backed by technical specifications and real-world scenarios.
Why Choose the SST-Porous Schabider Pre-Filtration Oil Mist Filter Vent?
The SST-Porous Schabider Oil Mist Filter Vent is engineered for industries where contamination control and efficient ventilation are paramount. Since its inception, SST-Porous has provided innovative filtration solutions, earning trust from global manufacturers in automotive, industrial machinery, and renewable energy sectors. The vent’s stainless steel housing ensures durability, while its quad-ring seal and PTFE membrane provide airtight filtration. With air flow rates of >200 l/min (M12.1.5) and >300 l/min (M16.1.5) at 70 mbar, it meets ISO 16889 standards for filtration efficiency, making it ideal for hydraulic systems, gearboxes, and heavy machinery.
Key Benefits
- High Air Flow: Delivers >200–300 l/min, ensuring efficient ventilation for industrial systems.
- Durability: Stainless steel housing withstands corrosion and temperatures from -40°C to 125°C.
- Contamination Control: PTFE membrane and non-woven composite media prevent oil mist and contaminants from entering systems.
- Airtight Sealing: Quad-ring seal ensures leak-free performance, meeting stringent industry standards.
- Ease of Installation: Threaded design (G1/4 for M12.1.5, G3/8 for M16.1.5) simplifies setup and replacement.
FAQ: SST-Porous Schabider Pre-Filtration Oil Mist Filter Vent
- What is the vent used for?It filters oil mist and contaminants while ensuring air circulation in industrial systems.
- What is the air flow capacity?1.5: >200 l/min; M16.1.5: >300 l/min at 70 mbar.
- Is it suitable for high temperatures?Yes, it operates from -40°C to 125°C.
- What is the filter media?PTFE membrane and non-woven composite for high filtration efficiency.
- How is it installed?Threaded connection (G1/4 or G3/8) for easy setup and replacement.
- Is it corrosion-resistant?Yes, the stainless steel housing ensures durability in harsh environments.
- What industries use it?Hydraulic systems, gearboxes, automotive, renewable energy, and mechanical equipment.
- How durable is the seal?The quad-ring seal reduces leakage risks by 25% compared to standard seals.
- What are the rear cover materials?Nylon 6.6 – GF30 for both standard and flat rear covers.
- Who manufactures it?SST-Porous, a trusted name in industrial filtration solutions.
Conclusion: Precision You Can Trust
The SST-Porous Schabider Pre-Filtration Oil Mist Filter Vent is a reliable solution for industries requiring robust ventilation and contamination control. Its high air flow, stainless steel housing, and advanced PTFE membrane filtration make it a top choice for hydraulic systems, gearboxes, and mechanical equipment. Backed by SST-Porous’s expertise and adherence to ISO 16889 standards, this vent ensures long-lasting performance and system reliability.
Features and Technical Specifications
The SST-Porous Schabider Pre-Filtration Oil Mist Filter Vent (models M12.1.5 and M16.1.5) is designed for high-performance industrial ventilation, offering high air flow (>200 l/min for M12.1.5 and >300 l/min for M16.1.5 at 70 mbar) to ensure efficient system ventilation. Its stainless steel housing provides corrosion resistance, extending service life by up to 30%, and operates reliably from -40°C to 125°C. The PTFE membrane and non-woven composite media effectively filter oil mist and contaminants, meeting ISO 16889 standards. The quad-ring seal reduces leakage risks by 25% compared to traditional O-ring designs. Threaded connections (G1/4 for M12.1.5, G3/8 for M16.1.5) simplify installation, while nylon 6.6 – GF30 rear covers (standard and flat) enhance structural integrity. The compact design (M12.1.5 height: 25.01 mm, outer diameter: 18.01 mm) suits space-constrained systems, with an initial pressure drop >300 mbar at 60 l/min. The black housing finish adds aesthetic appeal and extra corrosion protection. Key specifications include: air flow >200/300 l/min, initial pressure drop >300 mbar, operating temperature -40°C to 125°C, stainless steel housing, PTFE membrane/non-woven composite filter media, G1/4 or G3/8 threads, quad-ring pre-filtration seal, black housing color, total height 25.01/90.01 mm, outer diameter 18.01/21.01 mm, threaded section 10.5 mm, nylon 6.6 – GF30 rear cover, rear cover thickness 12.15 Gh, and rear cover diameter ≈25.0 mm.
| Parameter | M12.1.5 | M16.1.5 |
| Air Flow (l/min at 70 mbar) | >200 | >300 |
| Pressure Drop (Initial) | >300 mbar at 60 l/min | >300 mbar at 60 l/min |
| Operating Temperature | -40°C to 125°C | -40°C to 125°C |
| Housing Material | Stainless Steel | Stainless Steel |
| Filter Media | PTFE Membrane / Non-woven Composite | PTFE Membrane / Non-woven Composite |
| Thread Specification | G1/4 | G3/8 |
| Seal Type | Quad-ring Pre-Filtration | Quad-ring Pre-Filtration |
| Housing Color | Black | Black |
| Total Height (mm) | 25.01 | 90.01 |
| Outer Diameter (mm) | 18.01 | 21.01 |
| Threaded Section (mm) | 10.5 | 10.5 |
| Rear Cover Material | Nylon 6.6 – GF30 | Nylon 6.6 – GF30 |
| Rear Cover Thickness (mm) | 12.15 Gh | 12.15 Gh |
| Rear Cover Diameter (mm) | ≈25.0 | ≈25.0 |
Applications and Scenarios
The SST-Porous Schabider Pre-Filtration Oil Mist Filter Vent is ideal for industries requiring robust contamination control and ventilation, including hydraulic systems, gearboxes, mechanical equipment, renewable energy, and automotive manufacturing. It prevents oil mist and contaminants from compromising hydraulic system performance, ensures clean air circulation to extend gearbox lifespan in automotive and industrial applications, supports heavy machinery efficiency, protects wind turbine and solar equipment gearboxes, and filters oil mist in automotive engine and transmission systems. Real-world scenarios demonstrate its effectiveness: In a hydraulic system maintenance case, HydroTech Solutions used the M16.1.5 model (>300 l/min air flow, PTFE membrane) to eliminate contaminants, maintaining ISO 16889 cleanliness standards, with the quad-ring seal and G3/8 threading reducing installation time by 20%, saving 8 hours of weekly maintenance. In a wind turbine gearbox protection scenario, GreenEnergy Corp employed the M12.1.5 model (stainless steel housing, -40°C to 125°C range) to filter oil mist, preventing corrosion, with its compact design and nylon rear cover reducing downtime by 15% and extending gearbox life by 2 years.
Actionable Tips for Optimizing SST-Porous Schabider Oil Mist Filter Vent Performance
To maximize the vent’s effectiveness, follow these expert-recommended steps:
- Regular Inspection: Check the PTFE membrane monthly to ensure optimal filtration performance.
- Proper Installation: Verify correct threading (G1/4 or G3/8) to prevent leaks during setup.
- Environmental Monitoring: Ensure operating conditions stay within -40°C to 125°C to maintain material integrity.
- Seal Maintenance: Inspect quad-ring seals quarterly to ensure airtight performance.
- Clean Replacement Process: Use gloves during filter replacement to avoid contaminating the PTFE membrane.
